Section n°4 - SEALED CONNECTORS & CONTACTS

Title: Heavy Duty Sealed Connector Series SERIES CONNECTORS & CONTACTS

4.236 Heavy Duty Sealed Connector Series 1,5 Receptacle Housings

Code	Total Number of Ways	Kit Code	Color	Raw Material	Image
1/1418448/1	3	7082	black	pbt	A
Possible to buy in kit version: 7082 - KIT 3P PF HEAVY DUTY SEALED CONNECTOR SE
2/1418469/1	6	7331	grey	pbt	D
Possible to buy in kit version: 7331 - KIT PF 6 VIE 1,5 HEAVY DUTY SEALED CONN
2/1418448/1	3	7300	grey	pbt	B
Possible to buy in kit version: 7300 - KIT CONNETTORE 3 VIE PF HDSCS GRIGIO
1/1418469/1	6	7083	black	pbt	C
Possible to buy in kit version: 7083 - KIT 6P PF HEAVY DUTY SEALED CONNECTOR SE
1/1418479/1	8	7084	black	pbt	E
Possible to buy in kit version: 7084 - KIT 8P PF HEAVY DUTY SEALED CONNECTOR SE
1/1703639/1	12	7259	black	pbt	F
Possible to buy in kit version: 7259 - KIT CONNETTORE HDSCS 12 VIE PF
2/1703639/1	12	7148	black	pbt	G
Possible to buy in kit version: 7148 - KIT PF 12P HEAVY DUTY SEALED CONNECTOR S

4.236 Heavy Duty Sealed Connector Series 1,5 Receptacle Housings

Code:	1/1418448/1
Total Number of Ways:	3
Kit Code:	7082
Color:	black
Raw Material:	pbt
Image:	A

Possible to buy in kit version: 7082 - KIT 3P PF HEAVY DUTY SEALED CONNECTOR SE

Code:	2/1418469/1
Total Number of Ways:	6
Kit Code:	7331
Color:	grey
Raw Material:	pbt
Image:	D

Possible to buy in kit version: 7331 - KIT PF 6 VIE 1,5 HEAVY DUTY SEALED CONN

Code:	2/1418448/1
Total Number of Ways:	3
Kit Code:	7300
Color:	grey
Raw Material:	pbt
Image:	B

Possible to buy in kit version: 7300 - KIT CONNETTORE 3 VIE PF HDSCS GRIGIO

Code:	1/1418469/1
Total Number of Ways:	6
Kit Code:	7083
Color:	black
Raw Material:	pbt
Image:	C

Possible to buy in kit version: 7083 - KIT 6P PF HEAVY DUTY SEALED CONNECTOR SE

Code:	1/1418479/1
Total Number of Ways:	8
Kit Code:	7084
Color:	black
Raw Material:	pbt
Image:	E

Possible to buy in kit version: 7084 - KIT 8P PF HEAVY DUTY SEALED CONNECTOR SE

Code:	1/1703639/1
Total Number of Ways:	12
Kit Code:	7259
Color:	black
Raw Material:	pbt
Image:	F

Possible to buy in kit version: 7259 - KIT CONNETTORE HDSCS 12 VIE PF

Code:	2/1703639/1
Total Number of Ways:	12
Kit Code:	7148
Color:	black
Raw Material:	pbt
Image:	G

Possible to buy in kit version: 7148 - KIT PF 12P HEAVY DUTY SEALED CONNECTOR S

4.237 Heavy Duty Sealed Connector Series 1,5 Receptacle Contact

Code	Industrial Code	Wire Size Range (mm2)	Raw Material	Extraction Tool	Hand Tool
3415	1241380/1	0,50 - 1,00	Bz Ph Sn	132225, 24008	3989 + 3989/2

4.237 Heavy Duty Sealed Connector Series 1,5 Receptacle Contact

Code:	3415
Industrial Code:	1241380/1
Wire Size Range (mm2):	0,50 - 1,00
Raw Material:	Bz Ph Sn
Extraction Tool:	132225, 24008
Hand Tool:	3989 + 3989/2

4.238 Heavy Duty Sealed Connector Series Single Wire Seal

Code	Wire Size Range (mm2)	Color	Raw Material	Ext. Diam.	Contact Size
963530/1	0,50 - 0,75	grey	silicone	3,9	1,5

828904/1	1,00 - 2,00	blue	silicone	5,6	-

828905/1	2,00 - 2,50	white	silicone	5,6	2,8

963531/1	Plug	white	silicone	3,9	1,5

828922/1	Plug	transparent	silicone	5,6	2,8

4.238 Heavy Duty Sealed Connector Series Single Wire Seal

Code:	963530/1
Wire Size Range (mm2):	0,50 - 0,75
Color:	grey
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828904/1
Wire Size Range (mm2):	1,00 - 2,00
Color:	blue
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	-

Code:	828905/1
Wire Size Range (mm2):	2,00 - 2,50
Color:	white
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

Code:	963531/1
Wire Size Range (mm2):	Plug
Color:	white
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828922/1
Wire Size Range (mm2):	Plug
Color:	transparent
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

4.239 Cover 90° for Heavy Duty Sealed Connector Series

Code	Color	Application
75566	black	Connectors 2, 6, 8 ways

4.239 Cover 90° for Heavy Duty Sealed Connector Series

Code:	75566
Color:	black
Application:	Connectors 2, 6, 8 ways

4.240 Heavy Duty Sealed Connector Series 1,5+2,8 Receptacle Housings

Code	Total Number of Ways	Kit Code	Color	Raw Material	Image
1/1418480/1	7	7081	black	pbt	A
Possible to buy in kit version: 7081 - KIT 7P PF HEAVY DUTY SEALED CONNECTOR SE
2/1418480/1	7	7389	grey	pbt	B
Possible to buy in kit version: 7389 - KIT 1,5+2,8 PF 7 VIE GRIGIO HEAVY DUTY S
1/1563878/1	15	7092	black	pbt	C
Possible to buy in kit version: 7092 - KIT 15P PF HEAVY DUTY SEALED CONNECTOR S
1/1564337/1	16	7201	black	pbt	D
Possible to buy in kit version: 7201 - KIT PF 16P HEAVY DUTY SEALED CONNECTOR
2/1564337/1	16	7241	black	pbt	E
Possible to buy in kit version: 7241 - KIT PF 16P HEAVY DUTY SEALED CONNECTOR

4.240 Heavy Duty Sealed Connector Series 1,5+2,8 Receptacle Housings

Code:	1/1418480/1
Total Number of Ways:	7
Kit Code:	7081
Color:	black
Raw Material:	pbt
Image:	A

Possible to buy in kit version: 7081 - KIT 7P PF HEAVY DUTY SEALED CONNECTOR SE

Code:	2/1418480/1
Total Number of Ways:	7
Kit Code:	7389
Color:	grey
Raw Material:	pbt
Image:	B

Possible to buy in kit version: 7389 - KIT 1,5+2,8 PF 7 VIE GRIGIO HEAVY DUTY S

Code:	1/1563878/1
Total Number of Ways:	15
Kit Code:	7092
Color:	black
Raw Material:	pbt
Image:	C

Possible to buy in kit version: 7092 - KIT 15P PF HEAVY DUTY SEALED CONNECTOR S

Code:	1/1564337/1
Total Number of Ways:	16
Kit Code:	7201
Color:	black
Raw Material:	pbt
Image:	D

Possible to buy in kit version: 7201 - KIT PF 16P HEAVY DUTY SEALED CONNECTOR

Code:	2/1564337/1
Total Number of Ways:	16
Kit Code:	7241
Color:	black
Raw Material:	pbt
Image:	E

Possible to buy in kit version: 7241 - KIT PF 16P HEAVY DUTY SEALED CONNECTOR

4.241 Heavy Duty Sealed Connector 1,5 Serie Single Wire Seal

Code	Industrial Code	Wire Size Range (mm2)	Raw Material	Extraction Tool	Hand Tool
3415	1241380/1	0,50 - 1,00	Bz Ph Sn	132225, 24008	3989 + 3989/2

4.241 Heavy Duty Sealed Connector 1,5 Serie Single Wire Seal

Code:	3415
Industrial Code:	1241380/1
Wire Size Range (mm2):	0,50 - 1,00
Raw Material:	Bz Ph Sn
Extraction Tool:	132225, 24008
Hand Tool:	3989 + 3989/2

4.242 Heavy Duty Sealed Connector Serie Single Wire Seal

Code	Industrial Code	Wire Size Range (mm2)	Raw Material	Extraction Tool	Hand Tool
3417	967542/1	0,50 - 1,00	Bz Ph Sn	88040, 24000	3976 + 3982

3414	1/968857/1	1,00 - 2,50	Cu Ni Si	24000	3976 + 3982

4.242 Heavy Duty Sealed Connector Serie Single Wire Seal

Code:	3417
Industrial Code:	967542/1
Wire Size Range (mm2):	0,50 - 1,00
Raw Material:	Bz Ph Sn
Extraction Tool:	88040, 24000
Hand Tool:	3976 + 3982

Code:	3414
Industrial Code:	1/968857/1
Wire Size Range (mm2):	1,00 - 2,50
Raw Material:	Cu Ni Si
Extraction Tool:	24000
Hand Tool:	3976 + 3982

4.243 Heavy Duty Sealed Connector Serie Single Wire Seal

Code	Wire Size Range (mm2)	Color	Raw Material	Ext. Diam.	Contact Size
963530/1	0,50 - 0,75	grey	silicone	3,9	1,5

828904/1	1,00 - 2,00	blue	silicone	5,6	-

828905/1	2,00 - 2,50	white	silicone	5,6	2,8

963531/1	Plug	white	silicone	3,9	1,5

828922/1	Plug	transparent	silicone	5,6	2,8

4.243 Heavy Duty Sealed Connector Serie Single Wire Seal

Code:	963530/1
Wire Size Range (mm2):	0,50 - 0,75
Color:	grey
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828904/1
Wire Size Range (mm2):	1,00 - 2,00
Color:	blue
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	-

Code:	828905/1
Wire Size Range (mm2):	2,00 - 2,50
Color:	white
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

Code:	963531/1
Wire Size Range (mm2):	Plug
Color:	white
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828922/1
Wire Size Range (mm2):	Plug
Color:	transparent
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

4.244 Cover 90° for Heavy Duty Sealed Connector Series

Code	Color	Application
75566	black	Connectors 2, 6, 8 ways

4.244 Cover 90° for Heavy Duty Sealed Connector Series

Code:	75566
Color:	black
Application:	Connectors 2, 6, 8 ways

4.245 Heavy Duty Sealed Connector Series 2,8 Receptacle Housings

Code	Total Number of Ways	Kit Code	Color	Raw Material	Image
1/1418483/1	2	7079	black	pbt	A
Possible to buy in kit version: 7079 - KIT 2P PF HEAVY DUTY SEALED CONNECTOR SE
2/1418390/1	4	7307	grey	pbt	B
Possible to buy in kit version: 7307 - KIT CONNETTORE 4 VIE PF HDSCS 2.8 GRIGIO
1/1418390/1	4	7080	black	pbt	C
Possible to buy in kit version: 7080 - KIT 4P PF HEAVY DUTY SEALED CONNECTOR SE
3/1418390/1	4	7270	black/yellow	pbt	D
Possible to buy in kit version: 7270 - KIT PF 4P MCP 2.8 VERDE
1/1670894/1	8	7294	black	pbt	E
Possible to buy in kit version: 7294 - KIT CONNETTORE 8 VIE PF HDSCS 2,8

4.245 Heavy Duty Sealed Connector Series 2,8 Receptacle Housings

Code:	1/1418483/1
Total Number of Ways:	2
Kit Code:	7079
Color:	black
Raw Material:	pbt
Image:	A

Possible to buy in kit version: 7079 - KIT 2P PF HEAVY DUTY SEALED CONNECTOR SE

Code:	2/1418390/1
Total Number of Ways:	4
Kit Code:	7307
Color:	grey
Raw Material:	pbt
Image:	B

Possible to buy in kit version: 7307 - KIT CONNETTORE 4 VIE PF HDSCS 2.8 GRIGIO

Code:	1/1418390/1
Total Number of Ways:	4
Kit Code:	7080
Color:	black
Raw Material:	pbt
Image:	C

Possible to buy in kit version: 7080 - KIT 4P PF HEAVY DUTY SEALED CONNECTOR SE

Code:	3/1418390/1
Total Number of Ways:	4
Kit Code:	7270
Color:	black/yellow
Raw Material:	pbt
Image:	D

Possible to buy in kit version: 7270 - KIT PF 4P MCP 2.8 VERDE

Code:	1/1670894/1
Total Number of Ways:	8
Kit Code:	7294
Color:	black
Raw Material:	pbt
Image:	E

Possible to buy in kit version: 7294 - KIT CONNETTORE 8 VIE PF HDSCS 2,8

4.246 Heavy Duty Sealed Connector Series 2,8 Receptacle Contact

Code	Industrial Code	Wire Size Range (mm2)	Raw Material	Extraction Tool	Hand Tool
3417	967542/1	0,50 - 1,00	Bz Ph Sn	88040, 24000	3976 + 3982

3414	1/968857/1	1,00 - 2,50	Cu Ni Si	24000	3976 + 3982

4.246 Heavy Duty Sealed Connector Series 2,8 Receptacle Contact

Code:	3417
Industrial Code:	967542/1
Wire Size Range (mm2):	0,50 - 1,00
Raw Material:	Bz Ph Sn
Extraction Tool:	88040, 24000
Hand Tool:	3976 + 3982

Code:	3414
Industrial Code:	1/968857/1
Wire Size Range (mm2):	1,00 - 2,50
Raw Material:	Cu Ni Si
Extraction Tool:	24000
Hand Tool:	3976 + 3982

4.247 Heavy Duty Sealed Serie Single Wire Seal

Code	Wire Size Range (mm2)	Color	Raw Material	Ext. Diam.	Contact Size
963530/1	0,50 - 0,75	grey	silicone	3,9	1,5

828904/1	1,00 - 2,00	blue	silicone	5,6	-

828905/1	2,00 - 2,50	white	silicone	5,6	2,8

963531/1	Plug	white	silicone	3,9	1,5

828922/1	Plug	transparent	silicone	5,6	2,8

4.247 Heavy Duty Sealed Serie Single Wire Seal

Code:	963530/1
Wire Size Range (mm2):	0,50 - 0,75
Color:	grey
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828904/1
Wire Size Range (mm2):	1,00 - 2,00
Color:	blue
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	-

Code:	828905/1
Wire Size Range (mm2):	2,00 - 2,50
Color:	white
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

Code:	963531/1
Wire Size Range (mm2):	Plug
Color:	white
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828922/1
Wire Size Range (mm2):	Plug
Color:	transparent
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

4.248 Cover 90° for Heavy Duty Sealed Connector Series

Code	Color	Application
75566	black	Connectors 2, 6, 8 ways

4.248 Cover 90° for Heavy Duty Sealed Connector Series

Code:	75566
Color:	black
Application:	Connectors 2, 6, 8 ways

4.249 Heavy Duty Sealed Connector Series 1,5 Tab Housings

Code	Total Number of Ways	Kit Code	Color	Raw Material	Image
1/1703773/1	6	7444	black	pbt	C
Possible to buy in kit version: 7444 - KIT PM 6 VIE 1,5 HEAVY DUTY SEALED CONNE
2/1670730/1	3	7301	grey	pbt	A
Possible to buy in kit version: 7301 - KIT CONNETTORE 3 VIE PM HDSCS GRIGIO
1/1670730/1	3	7086	black	Pbt	B
Possible to buy in kit version: 7086 - KIT 3P PM HEAVY DUTY SEALED CONNECTOR SE
1/1564416/1	8	7137	black	pbt	D
Possible to buy in kit version: 7137 - KIT PM HEAVY DUTY SEALED CONNECTOR SERIE
1/1564414/1	12	7260	black	pbt	E
Possible to buy in kit version: 7260 - KIT CONNETTORE HDSCS 12 VIE PM
2/1564414/1	12	7393	grey	pbt	F
Possible to buy in kit version: 7393 - KIT 12 VIE PM GRIGIO HEAVY DUTY SEALED C
1/1564528/1	15	7405	black	pbt	G
Possible to buy in kit version: 7405 - KIT 1,5+2,8 PM 16 VIE HEAVY DUTY SEALED

4.249 Heavy Duty Sealed Connector Series 1,5 Tab Housings

Code:	1/1703773/1
Total Number of Ways:	6
Kit Code:	7444
Color:	black
Raw Material:	pbt
Image:	C

Possible to buy in kit version: 7444 - KIT PM 6 VIE 1,5 HEAVY DUTY SEALED CONNE

Code:	2/1670730/1
Total Number of Ways:	3
Kit Code:	7301
Color:	grey
Raw Material:	pbt
Image:	A

Possible to buy in kit version: 7301 - KIT CONNETTORE 3 VIE PM HDSCS GRIGIO

Code:	1/1670730/1
Total Number of Ways:	3
Kit Code:	7086
Color:	black
Raw Material:	Pbt
Image:	B

Possible to buy in kit version: 7086 - KIT 3P PM HEAVY DUTY SEALED CONNECTOR SE

Code:	1/1564416/1
Total Number of Ways:	8
Kit Code:	7137
Color:	black
Raw Material:	pbt
Image:	D

Possible to buy in kit version: 7137 - KIT PM HEAVY DUTY SEALED CONNECTOR SERIE

Code:	1/1564414/1
Total Number of Ways:	12
Kit Code:	7260
Color:	black
Raw Material:	pbt
Image:	E

Possible to buy in kit version: 7260 - KIT CONNETTORE HDSCS 12 VIE PM

Code:	2/1564414/1
Total Number of Ways:	12
Kit Code:	7393
Color:	grey
Raw Material:	pbt
Image:	F

Possible to buy in kit version: 7393 - KIT 12 VIE PM GRIGIO HEAVY DUTY SEALED C

Code:	1/1564528/1
Total Number of Ways:	15
Kit Code:	7405
Color:	black
Raw Material:	pbt
Image:	G

Possible to buy in kit version: 7405 - KIT 1,5+2,8 PM 16 VIE HEAVY DUTY SEALED

4.250 Heavy Duty Sealed Connector Series 1,5 Tab Contact

Code	Industrial Code	Wire Size Range (mm2)	Raw Material	Extraction Tool	Hand Tool
3416	964269/2	0,50 - 1,00	Bz Ph Sn	24008	3989 + 3989/2

4.250 Heavy Duty Sealed Connector Series 1,5 Tab Contact

Code:	3416
Industrial Code:	964269/2
Wire Size Range (mm2):	0,50 - 1,00
Raw Material:	Bz Ph Sn
Extraction Tool:	24008
Hand Tool:	3989 + 3989/2

4.251 Heavy Duty Sealed Connector Serie Single Wire Seal

Code	Wire Size Range (mm2)	Color	Raw Material	Ext. Diam.	Contact Size
963530/1	0,50 - 0,75	grey	silicone	3,9	1,5

828904/1	1,00 - 2,00	blue	silicone	5,6	-

828905/1	2,00 - 2,50	white	silicone	5,6	2,8

963531/1	Plug	white	silicone	3,9	1,5

828922/1	Plug	transparent	silicone	5,6	2,8

4.251 Heavy Duty Sealed Connector Serie Single Wire Seal

Code:	963530/1
Wire Size Range (mm2):	0,50 - 0,75
Color:	grey
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828904/1
Wire Size Range (mm2):	1,00 - 2,00
Color:	blue
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	-

Code:	828905/1
Wire Size Range (mm2):	2,00 - 2,50
Color:	white
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

Code:	963531/1
Wire Size Range (mm2):	Plug
Color:	white
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828922/1
Wire Size Range (mm2):	Plug
Color:	transparent
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

4.252 Cover 90° for Heavy Duty Sealed Connector Series

Code	Color	Application
75566	black	Connectors 2, 6, 8 ways

4.252 Cover 90° for Heavy Duty Sealed Connector Series

Code:	75566
Color:	black
Application:	Connectors 2, 6, 8 ways

4.253 Heavy Duty Sealed Connector Series 1,5+2,8 Tab Housings

Code	Total Number of Ways	Kit Code	Color	Raw Material	Image
1/1703648/1	7	7085	black	pbt	A
Possible to buy in kit version: 7085 - KIT 7P PM HEAVY DUTY SEALED CONNECTOR SE
1/1564518/1	10	7322	black	pbt	B
Possible to buy in kit version: 7322 - KIT PM 10 VIE HEAVY DUTY SEALED CONNECT
1/1564530/1	15	7192	black	pbt	C
Possible to buy in kit version: 7192 - KIT PM 15P HEAVY DUTY SEALED CONNECTOR S

4.253 Heavy Duty Sealed Connector Series 1,5+2,8 Tab Housings

Code:	1/1703648/1
Total Number of Ways:	7
Kit Code:	7085
Color:	black
Raw Material:	pbt
Image:	A

Possible to buy in kit version: 7085 - KIT 7P PM HEAVY DUTY SEALED CONNECTOR SE

Code:	1/1564518/1
Total Number of Ways:	10
Kit Code:	7322
Color:	black
Raw Material:	pbt
Image:	B

Possible to buy in kit version: 7322 - KIT PM 10 VIE HEAVY DUTY SEALED CONNECT

Code:	1/1564530/1
Total Number of Ways:	15
Kit Code:	7192
Color:	black
Raw Material:	pbt
Image:	C

Possible to buy in kit version: 7192 - KIT PM 15P HEAVY DUTY SEALED CONNECTOR S

4.254 Heavy Duty Sealed Connector Serie 1,5 Tab Contact

Code	Industrial Code	Wire Size Range (mm2)	Raw Material	Extraction Tool	Hand Tool
3416	964269/2	0,50 - 1,00	Bz Ph Sn	24008	3989 + 3989/2

4.254 Heavy Duty Sealed Connector Serie 1,5 Tab Contact

Code:	3416
Industrial Code:	964269/2
Wire Size Range (mm2):	0,50 - 1,00
Raw Material:	Bz Ph Sn
Extraction Tool:	24008
Hand Tool:	3989 + 3989/2

4.255 Heavy Duty Sealed Connector Serie 2,8 Tab Contact

Code	Industrial Code	Wire Size Range (mm2)	Raw Material	Extraction Tool	Hand Tool
3418	2/964300/1	0,5 - 2,0	Bz Ph Sn	24000	3976 + 3982

2/963749/1	2/962916/1	1,00 - 2,50	Bz Ph Sn	88040	3976

4.255 Heavy Duty Sealed Connector Serie 2,8 Tab Contact

Code:	3418
Industrial Code:	2/964300/1
Wire Size Range (mm2):	0,5 - 2,0
Raw Material:	Bz Ph Sn
Extraction Tool:	24000
Hand Tool:	3976 + 3982

Code:	2/963749/1
Industrial Code:	2/962916/1
Wire Size Range (mm2):	1,00 - 2,50
Raw Material:	Bz Ph Sn
Extraction Tool:	88040
Hand Tool:	3976

4.256 Heavy Duty Sealed Connector Serie Single Wire Seal

Code	Wire Size Range (mm2)	Color	Raw Material	Ext. Diam.	Contact Size
963530/1	0,50 - 0,75	grey	silicone	3,9	1,5

828904/1	1,00 - 2,00	blue	silicone	5,6	-

828905/1	2,00 - 2,50	white	silicone	5,6	2,8

963531/1	Plug	white	silicone	3,9	1,5

828922/1	Plug	transparent	silicone	5,6	2,8

4.256 Heavy Duty Sealed Connector Serie Single Wire Seal

Code:	963530/1
Wire Size Range (mm2):	0,50 - 0,75
Color:	grey
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828904/1
Wire Size Range (mm2):	1,00 - 2,00
Color:	blue
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	-

Code:	828905/1
Wire Size Range (mm2):	2,00 - 2,50
Color:	white
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

Code:	963531/1
Wire Size Range (mm2):	Plug
Color:	white
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828922/1
Wire Size Range (mm2):	Plug
Color:	transparent
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

4.257 Cover 90° for Heavy Duty Sealed Connector Series

Code	Color	Application
75566	black	Connectors 2, 6, 8 ways

4.257 Cover 90° for Heavy Duty Sealed Connector Series

Code:	75566
Color:	black
Application:	Connectors 2, 6, 8 ways

4.258 Heavy Duty Sealed Connector Series 2,8 Tab Housing

Code	Total Number of Ways	Kit Code	Color	Raw Material	Image
1/1703841/1	2	7227	black	pbt	A
Possible to buy in kit version: 7227 - KIT PM 2 VIE HEAVY DUTY SEALED CONNECTOR
1/1703818/1	4	7263	black	pbt	B
Possible to buy in kit version: 7263 - KIT AMP MCP 2.8 PM 4 VIE NERO
1/1564522/1	8	7295	black	pbt	C
Possible to buy in kit version: 7295 - KIT CONNETTORE 8 VIE PF HDSCS 2,8

4.258 Heavy Duty Sealed Connector Series 2,8 Tab Housing

Code:	1/1703841/1
Total Number of Ways:	2
Kit Code:	7227
Color:	black
Raw Material:	pbt
Image:	A

Possible to buy in kit version: 7227 - KIT PM 2 VIE HEAVY DUTY SEALED CONNECTOR

Code:	1/1703818/1
Total Number of Ways:	4
Kit Code:	7263
Color:	black
Raw Material:	pbt
Image:	B

Possible to buy in kit version: 7263 - KIT AMP MCP 2.8 PM 4 VIE NERO

Code:	1/1564522/1
Total Number of Ways:	8
Kit Code:	7295
Color:	black
Raw Material:	pbt
Image:	C

Possible to buy in kit version: 7295 - KIT CONNETTORE 8 VIE PF HDSCS 2,8

4.259 Heavy Duty Sealed Connector Serie 2,8 Tab Contact

Code	Industrial Code	Wire Size Range (mm2)	Raw Material	Extraction Tool	Hand Tool
3418	2/964300/1	0,5 - 2,0	Bz Ph Sn	24000	3976 + 3982

2/963749/1	2/962916/1	1,00 - 2,50	Bz Ph Sn	88040	3976

4.259 Heavy Duty Sealed Connector Serie 2,8 Tab Contact

Code:	3418
Industrial Code:	2/964300/1
Wire Size Range (mm2):	0,5 - 2,0
Raw Material:	Bz Ph Sn
Extraction Tool:	24000
Hand Tool:	3976 + 3982

Code:	2/963749/1
Industrial Code:	2/962916/1
Wire Size Range (mm2):	1,00 - 2,50
Raw Material:	Bz Ph Sn
Extraction Tool:	88040
Hand Tool:	3976

4.260 Heavy Duty Sealed Connector Serie Single Wire Seal

Code	Wire Size Range (mm2)	Color	Raw Material	Ext. Diam.	Contact Size
963530/1	0,50 - 0,75	grey	silicone	3,9	1,5

828904/1	1,00 - 2,00	blue	silicone	5,6	-

828905/1	2,00 - 2,50	white	silicone	5,6	2,8

963531/1	Plug	white	silicone	3,9	1,5

828922/1	Plug	transparent	silicone	5,6	2,8

4.260 Heavy Duty Sealed Connector Serie Single Wire Seal

Code:	963530/1
Wire Size Range (mm2):	0,50 - 0,75
Color:	grey
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828904/1
Wire Size Range (mm2):	1,00 - 2,00
Color:	blue
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	-

Code:	828905/1
Wire Size Range (mm2):	2,00 - 2,50
Color:	white
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

Code:	963531/1
Wire Size Range (mm2):	Plug
Color:	white
Raw Material:	silicone
Ext. Diam.:	3,9
Contact Size:	1,5

Code:	828922/1
Wire Size Range (mm2):	Plug
Color:	transparent
Raw Material:	silicone
Ext. Diam.:	5,6
Contact Size:	2,8

4.261 Cover 90° for Heavy Duty Sealed Connector Series

Code	Color	Application
75566	black	Connectors 2, 6, 8 ways

4.261 Cover 90° for Heavy Duty Sealed Connector Series

Code:	75566
Color:	black
Application:	Connectors 2, 6, 8 ways

Section summary
